APC Device IP Configuration Wizard 3.0.1 can be downloaded from our website for free. Apcutilg.exe is the frequent file name to indicate this program's installer. APC Device IP Configuration Wizard belongs to Internet & Network Tools. Our built-in antivirus checked this download and rated it as 100% safe. Network Management Device IP Configuration Wizard v5.0.3. Network Management Device IP Configuration Wizard v5.0.3. Thank you for registering for email from APC. American Power Conversion (APC) is a leading manufacturer of uninterruptible power supplies (UPS) and surge protection products for end-to-end legendary reliability. IPv6 network configuration provides flexibility to accommodate the user's requirements. To configure the TCP/IP settings for IPv6, see the user interface online help for details on the options: Manual, Auto Configuration, DHCPv6 Mode under this menu: Administration Network TCP/IP IPv6 settings. Network management features. Device IP Configuration Wizard You can use the Device IP Configuration Wizard at a computer running Microsoft® Windows® 2000, Windows Server® 2003, Windows XP, Windows Vista, Windows Server 2008, or Windows 7 to discover unconfigured Network Management Cards and configure their basic TCP/IP settings, one card at a time, over the network.
Download 128 pages, 930.29 Kb Success! {{ $ctrl.successMessage }}
0'>Errors!
>
Run the Wizard to perform the configuration. To discover and configure the unconfigured Rack
1.From the Start menu, launch the Wizard. The Wizard detects the first Rack PDU or network-
2.Select Remotely (over the network), and click Next >.
3.Enter the system IP, subnet mask, and default gateway for the Rack PDU or device identified by
On the Transmit Current Settings Remotely screen, if you check-mark Start a Web browser
when finished, the default Web browser connects to the Rack PDU or device after the Wizard
4.Click Finish to transmit the settings. If the IP address you entered is in use on the network, the
Wizard prompts you to enter an IP address that is not in use. Enter a correct IP address, and click
5.If the Wizard finds another unconfigured Rack PDU or device, it displays the screen to enter
TCP/IP settings. Repeat this procedure beginning at step 3, or to skip the Rack PDU or device
whose MAC address is currently displayed, click Cancel.
Configure or reconfigure the TCP/IP settings locally
Apc Network Management Device Ip Configuration Wizard V5.0.3 Download
1.Contact your network administrator to obtain valid TCP/IP settings.
2.Connect the provided serial configuration cable (APC part number 940-0144A) from an available
communications port on your computer to the serial port of the Rack PDU or device. Make sure
3.From the Start menu, launch the Wizard application.
4.If the Rack PDU or network-enabled device is not configured, wait for the Wizard to detect it.
5.Select Locally (through the serial port), and click Next >.
6.Enter the system IP, subnet mask, and default gateway for the Rack PDU or device, and click
7.On the Transmit Current Settings Remotely screen, if you select Start a Web browser when
finished, the default Web browser connects to the Rack PDU or device after the Wizard transmits
8.Click Finish to transmit the TCP/IP settings. If the IP address you entered is in use on the
network, the Wizard prompts you to enter an IP address that is not in use. Enter a correct IP
9.If you selected Start a Web browser when finished in step 6, you can now configure other
Apc Network Management Device Ip Configuration Wizard
parameters through the Web interface of the Rack PDU or device.
